| F SERIES | W2-852SH |
|
| ||||
| DIAPHRAGM MTL | Paper | ||||
| SURROUND MTL | TPR | ||||
| NOMINAL IMPEDANCE | 4 W | ||||
| DCR IMPEDANCE | 3.6 W | ||||
| SENSITIVITY 1W/1m | 86 dB | ||||
| FREQUENCY RESPONSE | 160-20K Hz | ||||
| FREE AIR RESONANCE | 160 Hz | ||||
| VOICE COIL DIAMETER | 20.4 mm | ||||
| AIR GAP HEIGHT | 3 mm | ||||
| RATED POWER INPUT | 8 W | ||||
| MAXIMUM POWER INPUT | 16 W | ||||
| FORCE FACTOR, BL | 2.99 TM | ||||
| MAGNET WEIGHT ( oz) | Neodymium | ||||
| MOVING MASS | 1 g | ||||
| FERRO FLUID ENHANCED | No | ||||
| SUSPENSION COMPL. | 1051 MN-1 | ||||
| EFFEC.PISTON AREA | 0.0013 M2 | ||||
| Levc | 0.03 mH | ||||
| Zo | 25 ohm | ||||
| X-max | 1 mm | ||||
| Vas | 0.25 Litr. | ||||
| Qts | 0.29 | ||||
| Qms | 1.49 | ||||
| Qes | 0.37 | ||||
 |
