| F SERIES | W3-583SE |
|
| |
| DIAPHRAGM MTL | Paper | |
| SURROUND MTL | Santoprene | |
| NOMINAL IMPEDANCE | 8 W | |
| DCR IMPEDANCE | 6.6 W | |
| SENSITIVITY 1W/1m | 87 dB | |
| FREQUENCY RESPONSE | 100-20K Hz | |
| FREE AIR RESONANCE | 100 Hz | |
| VOICE COIL DIAMETER | 20.4 mm | |
| AIR GAP HEIGHT | 6 mm | |
| RATED POWER INPUT | 12 W | |
| MAXIMUM POWER INPUT | 25 W | |
| FORCE FACTOR, BL | 2.99 TM | |
| MAGNET WEIGHT (4oz) | 103 g | |
| MOVING MASS | 1.54 g | |
| FERRO FLUID ENHANCED | No | |
| SUSPENSION COMPL. | 1689 uMN-1 | |
| EFFEC.PISTON AREA | 0.0032 M2 | |
| Levc | 0.051 mH | |
| Zo | 32.5 ohm | |
| X-max | 0.25 mm | |
| Vas | 2.46 Litr. | |
| Qts | 0.56 | |
| Qms | 2.75 | |
| Qes | 0.70 | |
 |
